Intel Arc A770 vs NVIDIA GeForce RTX 2070 Super
35.3Rasterization33.3
28.5Ray Tracing26.4
57.9Memoryspec-based45.7
81.9Efficiencyspec-based76.5
41.1Compute40.3
10 spec wins — Intel Arc A7706 spec wins — NVIDIA GeForce RTX 2070 Super
InnoReviews verdict
Intel Arc A770 wins this graphics card face-off, 45.2 to 41.3, pulling ahead mainly in Ray Tracing (+2) and rasterization (+2). NVIDIA GeForce RTX 2070 Super still makes sense if its price or standout specs fit your needs better.
Which would you pick?
Key differences
Reasons to pick the Intel Arc A770
- 100% higher VRAM: 16 GB vs 8 GB
- 60% higher Shading units: 4,096 vs 2,560
- 60% higher Tensor / AI cores: 512 vs 320
- 50% lower process: 6 nm vs 12 nm
- 44% higher 3DMark Time Spy: 13,500 vs 9,400
- Lower launch price: $349 vs $499
Reasons to pick the NVIDIA GeForce RTX 2070 Super
- 25% higher RT cores: 40 vs 32
- 11% higher 1080p Ultra: 94 fps vs 85 fps
General
| Spec | Intel Arc A770 | NVIDIA GeForce RTX 2070 Super |
|---|---|---|
| Announced | 2022 | 2019 |
| Architecture | Alchemist | Turing |
| Process | 6 nm+50% | 12 nm |
| TDP | 225 W | 215 W+4% |
| Power connector | 1x 8-pin + 1x 6-pin | 1x 8-pin + 1x 6-pin |
Cores & Clocks
| Spec | Intel Arc A770 | NVIDIA GeForce RTX 2070 Super |
|---|---|---|
| Shading units | 4,096+60% | 2,560 |
| RT cores | 32 | 40+25% |
| Tensor / AI cores | 512+60% | 320 |
| Base clock | 2,100 MHz+31% | 1,605 MHz |
| Boost clock | 2,400 MHz+36% | 1,770 MHz |
Memory
| Spec | Intel Arc A770 | NVIDIA GeForce RTX 2070 Super |
|---|---|---|
| VRAM | 16 GB+100% | 8 GB |
| VRAM type | GDDR6 | GDDR6 |
| Bus width | 256 bit | 256 bit |
| Bandwidth | 560 GB/s+25% | 448 GB/s |
Benchmarks
| Spec | Intel Arc A770 | NVIDIA GeForce RTX 2070 Super |
|---|---|---|
| 3DMark Time Spy | 13,500+44%Top 43% | 9,400Bottom 34% |
| 3DMark Speed Way | 2,600+18%Bottom 27% | 2,200Bottom 16% |
| PassMark G3D | 13,700Bottom 28% | 15,000+9%Bottom 38% |
| 1080p Ultra | 85 fpsBottom 17% | 94 fps+11%Bottom 28% |
| 1440p Ultra | 63 fpsBottom 21% | 67 fps+6%Bottom 28% |
| 4K Ultra | 34 fpsBottom 23% | 35 fps+3%Bottom 28% |
Features
| Spec | Intel Arc A770 | NVIDIA GeForce RTX 2070 Super |
|---|---|---|
| Upscaling | XeSS | DLSS 4 (no FG) |
