AMD Radeon RX 7800 XT vs NVIDIA RTX A5500
45Rasterization40.7
36.4Ray Tracing38.6
59.2Memoryspec-based71.2
78.4Efficiencyspec-based79.1
56.8Compute57.6
4 spec wins — AMD Radeon RX 7800 XT8 spec wins — NVIDIA RTX A5500
InnoReviews verdict
This one is close to a dead heat: AMD Radeon RX 7800 XT scores 52.2 against 53.1 for NVIDIA RTX A5500. Pick by the categories that matter to you — NVIDIA RTX A5500 edges ahead in Ray Tracing and compute, or by price.
Which would you pick?
Key differences
Reasons to pick the AMD Radeon RX 7800 XT
- Stronger rasterization score: 45 vs 41
- 37% lower process: 5 nm vs 8 nm
- 28% higher 3DMark Time Spy: 20,098 vs 15,681
- 15% higher PassMark G3D: 24,469 vs 21,192
- Lower launch price: $499 vs $3,600
Reasons to pick the NVIDIA RTX A5500
- 167% higher Shading units: 10,240 vs 3,840
- 167% higher Tensor / AI cores: 320 vs 120
- 50% higher VRAM: 24 GB vs 16 GB
- 50% higher Bus width: 384 bit vs 256 bit
- 33% higher RT cores: 80 vs 60
General
| Spec | AMD Radeon RX 7800 XT | NVIDIA RTX A5500 |
|---|---|---|
| Announced | 2023 | 2022 |
| Architecture | RDNA 3 | Ampere |
| Process | 5 nm+37% | 8 nm |
| TDP | 263 W | 230 W+13% |
| Power connector | 2x 8-pin | 1x 8-pin |
Cores & Clocks
| Spec | AMD Radeon RX 7800 XT | NVIDIA RTX A5500 |
|---|---|---|
| Shading units | 3,840 | 10,240+167% |
| RT cores | 60 | 80+33% |
| Tensor / AI cores | 120 | 320+167% |
| Boost clock | 2,430 MHz | — |
Memory
| Spec | AMD Radeon RX 7800 XT | NVIDIA RTX A5500 |
|---|---|---|
| VRAM | 16 GB | 24 GB+50% |
| VRAM type | GDDR6 | GDDR6 |
| Bus width | 256 bit | 384 bit+50% |
| Bandwidth | 624 GB/s | 768 GB/s+23% |
Benchmarks
| Spec | AMD Radeon RX 7800 XT | NVIDIA RTX A5500 |
|---|---|---|
| 3DMark Time Spy | 20,098+28%Top 24% | 15,681Top 38% |
| 3DMark Speed Way | 4,069Top 39% | 4,491+10%Top 29% |
| PassMark G3D | 24,469+15%Top 29% | 21,192Top 43% |
| 1080p Ultra | 121 fpsTop 50% | — |
| 1440p Ultra | 90 fpsTop 48% | — |
| 4K Ultra | 52 fpsTop 48% | — |
Features
| Spec | AMD Radeon RX 7800 XT | NVIDIA RTX A5500 |
|---|---|---|
| Upscaling | FSR 3 | DLSS |
