AMD Radeon RX 5700 vs AMD Radeon RX 6600
29.8Rasterization30.1
20Ray Tracing22.7
45.7Memoryspec-based37.1
86.4Efficiencyspec-based92.3
38.5Compute36.6
5 spec wins — AMD Radeon RX 57004 spec wins — AMD Radeon RX 6600
InnoReviews verdict
This one is close to a dead heat: AMD Radeon RX 5700 scores 40 against 40 for AMD Radeon RX 6600. Pick by the categories that matter to you — AMD Radeon RX 5700 edges ahead in compute, or by price.
Which would you pick?
Key differences
Reasons to pick the AMD Radeon RX 5700
- 100% higher Bus width: 256 bit vs 128 bit
- 100% higher bandwidth: 448 GB/s vs 224 GB/s
- 29% higher Shading units: 2,304 vs 1,792
Reasons to pick the AMD Radeon RX 6600
- 44% higher Boost clock: 2,491 MHz vs 1,725 MHz
- 27% lower TDP: 132 W vs 180 W
- 11% higher Base clock: 1,626 MHz vs 1,465 MHz
General
| Spec | AMD Radeon RX 5700 | AMD Radeon RX 6600 |
|---|---|---|
| Announced | 2019 | 2021 |
| Architecture | RDNA | RDNA 2 |
| Process | 7 nm | 7 nm |
| TDP | 180 W | 132 W+27% |
| Power connector | 1x 8-pin + 1x 6-pin | 1x 8-pin |
Cores & Clocks
| Spec | AMD Radeon RX 5700 | AMD Radeon RX 6600 |
|---|---|---|
| Shading units | 2,304+29% | 1,792 |
| RT cores | — | 28 |
| Base clock | 1,465 MHz | 1,626 MHz+11% |
| Boost clock | 1,725 MHz | 2,491 MHz+44% |
Memory
| Spec | AMD Radeon RX 5700 | AMD Radeon RX 6600 |
|---|---|---|
| VRAM | 8 GB | 8 GB |
| VRAM type | GDDR6 | GDDR6 |
| Bus width | 256 bit+100% | 128 bit |
| Bandwidth | 448 GB/s+100% | 224 GB/s |
Benchmarks
| Spec | AMD Radeon RX 5700 | AMD Radeon RX 6600 |
|---|---|---|
| 3DMark Time Spy | 8,500+1%Bottom 30% | 8,400Bottom 29% |
| 3DMark Speed Way | — | 1,500Bottom 4% |
| PassMark G3D | 14,204+2%Bottom 33% | 13,900Bottom 31% |
| 1080p Ultra | — | 76 fpsBottom 12% |
| 1440p Ultra | — | 53 fpsBottom 12% |
| 4K Ultra | — | 27 fpsBottom 12% |
Features
| Spec | AMD Radeon RX 5700 | AMD Radeon RX 6600 |
|---|---|---|
| Upscaling | FSR 1 | FSR 3 |
