AMD Radeon RX 5700 XT vs AMD Radeon RX 6600
31.5Rasterization30.1
20Ray Tracing22.7
45.7Memoryspec-based37.1
80.8Efficiencyspec-based92.3
41.8Compute36.6
5 spec wins — AMD Radeon RX 5700 XT4 spec wins — AMD Radeon RX 6600
InnoReviews verdict
This one is close to a dead heat: AMD Radeon RX 5700 XT scores 40.3 against 40 for AMD Radeon RX 6600. Pick by the categories that matter to you — AMD Radeon RX 5700 XT edges ahead in compute and rasterization, or by price.
Which would you pick?
Key differences
Reasons to pick the AMD Radeon RX 5700 XT
- Stronger compute score: 42 vs 37
- 100% higher Bus width: 256 bit vs 128 bit
- 100% higher bandwidth: 448 GB/s vs 224 GB/s
- 43% higher Shading units: 2,560 vs 1,792
- 15% higher PassMark G3D: 16,033 vs 13,900
Reasons to pick the AMD Radeon RX 6600
- 41% lower TDP: 132 W vs 225 W
- 31% higher Boost clock: 2,491 MHz vs 1,905 MHz
- Lower launch price: $329 vs $399
General
| Spec | AMD Radeon RX 5700 XT | AMD Radeon RX 6600 |
|---|---|---|
| Announced | 2019 | 2021 |
| Architecture | RDNA | RDNA 2 |
| Process | 7 nm | 7 nm |
| TDP | 225 W | 132 W+41% |
| Power connector | 1x 8-pin + 1x 6-pin | 1x 8-pin |
Cores & Clocks
| Spec | AMD Radeon RX 5700 XT | AMD Radeon RX 6600 |
|---|---|---|
| Shading units | 2,560+43% | 1,792 |
| RT cores | — | 28 |
| Base clock | 1,605 MHz | 1,626 MHz+1% |
| Boost clock | 1,905 MHz | 2,491 MHz+31% |
Memory
| Spec | AMD Radeon RX 5700 XT | AMD Radeon RX 6600 |
|---|---|---|
| VRAM | 8 GB | 8 GB |
| VRAM type | GDDR6 | GDDR6 |
| Bus width | 256 bit+100% | 128 bit |
| Bandwidth | 448 GB/s+100% | 224 GB/s |
Benchmarks
| Spec | AMD Radeon RX 5700 XT | AMD Radeon RX 6600 |
|---|---|---|
| 3DMark Time Spy | 9,596+14%Bottom 38% | 8,400Bottom 29% |
| 3DMark Speed Way | — | 1,500Bottom 4% |
| PassMark G3D | 16,033+15%Bottom 44% | 13,900Bottom 31% |
| 1080p Ultra | — | 76 fpsBottom 12% |
| 1440p Ultra | — | 53 fpsBottom 12% |
| 4K Ultra | — | 27 fpsBottom 12% |
Features
| Spec | AMD Radeon RX 5700 XT | AMD Radeon RX 6600 |
|---|---|---|
| Upscaling | FSR 1 | FSR 3 |
